Finishes: Silver

The Exidor 285 silver push bar with rim latch and vertical bolt is a dependable panic exit hardware solution designed for rebated double doors in high-traffic areas where emergency egress is essential. This EN 1125-compliant system features a non-handed panic latch (296) for the second closing leaf, a two-point panic bolt (294) for the first closing leaf, and a secure box keep (300), ensuring quick and safe evacuation during panic situations. Ideal for commercial buildings, the silver-finished push bar allows easy operation by withdrawing the rim latch and vertical bolts, suitable for timber or steel doors for versatile installation. Improve your door security with this durable, user-friendly emergency exit device that emphasises safety without sacrificing style.

Exidor 285 Silver | Push Bar - Rim Latch & Vertical Bolt (285)


Security Check


  • Additional Product Details

    The Exidor 285 for rebated double doors is a complete package consisting of a panic latch (296), a panic bolt (294), and a box keep (300).

    • Non-handed (universal)
    • Fire rated for use on timber and steel doors*
    • Surface-mounted
    • Microswitch option available**
    • Closed arm design
    • Max door thickness <51mm
    • Max door height <2440mm
    • Max door weight <200 kilos


    * For metal door fixings & keeps, please order Exidor 285SD.SILVER
    ** For microswitch options, order 285MS.SILVER or 285SD.MS.SILVER

    For key-controlled external access, use the Exidor 322EC Silver | Outside Access Device  (compatible with all Exidor Exit Devices). Please check Certifire approval for fire rating limitations.

    Available as standard in silver, there is also a choice of RAL colours and plated finishes.

    The Exidor 200/300 Series of escape hardware consists of a vertical bolt, rim latch, and mortice night latch operator. Each product is operated by a push pad (EN179) or horizontal bar (EN1125), which, when pushed in a downward arc, withdraws the locking element, releasing the door for immediate egress.

    Exidor Fire Door Closer | Exidor Exit Devices


    Relcross Limited (trading as) Door Hardware Online | Hambleton Avenue | DEVIZES | Wiltshire | SN10 2RT | United Kingdom | T: ++ 44 (0) 1380 720 062 | F: ++ 44 (0) 1380 729 888 |  E: britonsales@doorhardware-online.co.uk

  • Certification

    EN 1125: 2008

    UKCA | CE | Certifire | Fire Rated* | Warranty: 10 Years (Mechanical)

    Certificates, including DoPs, are downloadable here

    *Certifire approves the Exidor 200/300 series for use on timber and steel doors to EN 1634-1: 2000. The rating will depend on the certification of the fire door. It is essential to realise that the hardware is required for the first part of the test until the door is sealed into the frame. After this period, the fire door is then responsible for sealing off the area.

    Timber doors up to FD120 | Metal Doors up to FD120/FD240

  • Resources | Downloads

    Exidor 200/300 Series | Bolts & Latches Range - Catalogue

    Exidor 285 Silver | Push Bar - Rim Latch & Vertical Bolt (285) - Installation
