Briton 2130B.TE.C.SES | Electro HO Door Closer (2130)

Finishes: US28 Silver w. Matching Arm & Track

The Briton 2130B.TE.C.SES (now correctly known as the LCN 1460SE Sentronic®) is a high-performance electromagnetic hold-open door closer (also called an electro-hydraulic door closer or electrically held-open door closer) designed specifically for fire doors and smoke barrier doors in commercial, institutional, and public buildings. This version includes the LCN snap-on plastic cover and not the traditional 'Briton' box cover. The closer mechanism and arm are exactly as the original 2130B.TE Briton branded unit.

£0.00 inc VAT
£414.00 inc VAT
£0.00 ex VAT
£345.00 ex VAT
Earn0
reward points
  • Additional Product Details

    Electromagnetic Hold Open Standard Duty Closer 24Vac/dc w. Backcheck, Plastic Cover and Sentronic 24V Track. Spring Power Adjustable Size 3-4. Universal Track for Two Possible Applications*.

    This variant includes:

    Cylinder - 1460SE-3071
    Standard, non-handed cast iron cylinder assembly

    Standard Arm - 1460SE-3077T
    Non-handed arm.  The arm is adjustable to select the hold-open point

    SE Track - 4040SE-3038
    Non-handed. Mounts on either head frame or stop, 24Vac/dc input for holding solenoid
    Includes test switch assembly with fuse

    Track Roller - 4040SE-3034SE
    Quiet, low-friction roller assembly.  Shoulder dimension "X" = 3mm with Track Slider - 4040SE-168 Alloy metal slider for use in SE series tracks only

    Suits doors <102 kilos

    *UKCA & CE Certification applies to Hinge (Pull Side) Mounting Only

    Your compatible 24V power supply is available here: RGL 2402/4TRS | 24Vdc 2.0 Amp Power Supply (PSU)

    The 1460SE Sentronic® is a standard-duty, non-handed, non-sized closer/holder designed to provide single-point hold-open for fire and smoke barrier doors. The door remains open until the current interruption releases the holding mechanism, after which it closes. This single-lever (track) arm closer is designed for interior doors. A choice of finishes, track functions and installation accessories meet virtually all life safety requirements.

    • Standard 1460SE series closer shipped with a standard arm, 24V SE track, standard cover and wood & machine screw pack
    • Non-sized cylinders for interior doors to 1220mm
    • Hold-open force is adjustable
    • Momentary on/off switchboard assembly for testing door release, also provides over-voltage protection. Field replaceable
    • Functions as a full rack and pinion closer when hold-open is not engaged or current is interrupted
    • Closer mounts on either push or pull side of the door
    • Non-handed for mounting on either right or left-hand door
    • Universal Sentronic track offers concealed or surface wiring
    • Interfaces with alarm systems. Consult Relcross for full details
    • Standard or optional custom powder-coated finishes on the cover, arm and fasteners
    • Optional plated finishes
    • Non-handed
    • Requires additional system components
    • Surface Mounting
    • For interior fire and smoke barrier doors. Single-acting cylinder on the door top rail
    • Exposed arm and track to the head frame
    • Maximum Opening - Butt hinge template allows 110° with hold open points between 85° and 110°
    • Optional SEL special long track allows hold open points between 90° and 120° in approximately 3° increments
    • Consult Relcross for all pivot-mounted installations
    • Butt Hinges should not exceed 127mm in width.
    • Auxiliary Stop is recommended at the hold open point
    • All Weather Fluid - Performs without variation: Manual Closers - between -35° to +49°, Electronic HO Closers & Automatic Operators - between +2° to +49°C, At approx. +75°C the fluid will begin to leak from the mechanism. The flash point is approximately. 110°C


    Designed for maximum versatility, the 1460 Series, available with multiple cover options, is suitable for both commercial and institutional applications. This fully universal closer (1461) offers a wide variety of options and a new, fast & accurate installation.

    Briton Fire Door Closers | Briton Exit Devices | Briton Locks | LCN Closers


    Relcross Limited (trading as) Door Hardware Online | Hambleton Avenue | DEVIZES | Wiltshire | SN10 2RT | United Kingdom | T: ++ 44 (0) 1380 720 062 | F: ++ 44 (0) 1380 729 888 |  E: britonsales@doorhardware-online.co.uk

  • Certification

    UK Fire Certification in accordance with BS EN 1634-1:2014 (timber) - 120 mins
    WFRC No. 142058

    EN 1154: 1996 + A1: 2002/AC:2006
    EN 1155: 1997 + A1: 2002

    UKCA | CE | ANSI | UL | 120 Mins Timber | Warranty: 10 Years (Mechanical), 2 Years (Electrical)

    Certificates, including DoPs downloadable here

  • Resources | Downloads

    LCN 1460SE.US28 | Electro HO Door Closer - Connections

    LCN 1460SE.US28 | Electro HO Door Closer - Installation
